1 kΩ, Surface Mount Trimmer Potentiometer, J-Hook 0.125 W Top Adjust Bourns, 3313 | 3313J-1-102E
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 13 pcs
Mfr. Part No: 3313J-1-102E
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Bourns |
| Maximum Resistance | 1kΩ |
| Product Type | Trimmer Potentiometer |
| Mount Type | Surface Mount |
| Number of Turns | 1 |
| Orientation | Top Adjust |
| Packaging | Tape & Reel |
| Power Rating | 0.125W |
| Series | 3313 |
| Automotive Standard | No |
| Termination Style | J-Hook |
| Tolerance ± | 20% |
| Temperature Coefficient | ±100 ppm/°C |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | 125°C |
| Shaft Diameter | 1.93mm |
| Length | 3.2mm |
| Standards/Approvals | RoHS, UL |
| Depth | 2.2mm |
| Height | 3.5mm |
| Mechanical Rotation | 250° |
| Element Material | Cermet |
Product Details
125mW 3mm 3313J Series
Horizontal 3 mm Square Sealed Trimming Potentiometer
Compatible with surface mount manufacturing processes
Rotor stop for “in-circuit” adjustment
100 cycle rotational and seal life
Patent #5043695 assembly for seal integrity
Plastic housing for RF applications
