1 kΩ, Surface Mount Trimmer Potentiometer, J-Hook 0.25 W Top Adjust Bourns, PVG5 | PVG5A102C03R00
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 10 pcs
Mfr. Part No: PVG5A102C03R00
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Bourns |
| Product Type | Trimmer Potentiometer |
| Maximum Resistance | 1kΩ |
| Mount Type | Surface Mount |
| Number of Turns | 12 |
| Packaging | Tape & Reel |
| Orientation | Top Adjust |
| Power Rating | 0.25W |
| Series | PVG5 |
| Termination Style | J-Hook |
| Automotive Standard | No |
| Tolerance ± | 10% |
| Temperature Coefficient | ±150 ppm/°C |
| Minimum Operating Temperature | -55°C |
| Shaft Length | 0.6mm |
| Shaft Diameter | 1.5mm |
| Length | 4.8mm |
| Maximum Operating Temperature | 125°C |
| Standards/Approvals | IPC, EIA, RoHS, EIAJ, ISO, VECI |
| Height | 5.1mm |
| Depth | 3.9mm |
| Element Material | Cermet |
Product Details
11-Turn 250mW 5mm Top Adjust PVG5A Series
11 turn high resolution trimmers permitting accurate adjustment
Compatible with the VPS wave soldering standard and passing through the ultra-sounds tank
Clutch mechanism prevents excessive wiper rotation
Applications: sensors, industrial machines, CPU’s, measuring instruments
Multi-Turn Surface Mount Trimmers
