1 kΩ, Surface Mount Trimmer Potentiometer, Pin 0.5 W Top Adjust Bourns, 3361 | 3361P-1-102GLF
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 6 pcs
Mfr. Part No: 3361P-1-102GLF
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Bourns |
| Product Type | Trimmer Potentiometer |
| Maximum Resistance | 1kΩ |
| Mount Type | Surface Mount |
| Number of Turns | 1 |
| Packaging | Tape & Reel |
| Orientation | Top Adjust |
| Power Rating | 0.5W |
| Series | 3361 |
| Automotive Standard | No |
| Termination Style | Pin |
| Tolerance ± | 10% |
| Temperature Coefficient | ±100 ppm/°C |
| Minimum Operating Temperature | -55°C |
| Shaft Length | 0.64mm |
| Maximum Operating Temperature | 125°C |
| Length | 6.71mm |
| Depth | 5.21mm |
| Height | 7.04mm |
| Standards/Approvals | RoHS, UL |
| Element Material | Cermet |
| Mechanical Rotation | 270° |
Product Details
Cermet 1/4 in. Square 500mW Top Adjust 3361P Series
Bourns® 3361 Series 1/4 Square Single turn Cermet SMD Trimpot® Trimming Potentiometer.
Industrial / Sealed
Miniature package
Rotor designed for automatic machine adjust Interface
Withstands harsh environments and immersion cleaning processes
Compatible with surface mount manufacturing processes
