1 kΩ, Through Hole Trimmer Potentiometer, Pin 0.5 W Side Adjust Bourns, 3296 | 3296P-1-102LF
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 13 pcs
Mfr. Part No: 3296P-1-102LF
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Bourns |
| Product Type | Trimmer Potentiometer |
| Maximum Resistance | 1kΩ |
| Mount Type | Through Hole |
| Number of Turns | 25 |
| Packaging | Tube |
| Orientation | Side Adjust |
| Power Rating | 0.5W |
| Series | 3296 |
| Automotive Standard | No |
| Termination Style | Pin |
| Tolerance ± | 10% |
| Temperature Coefficient | ±100 ppm/°C |
| Minimum Operating Temperature | -55°C |
| Pin Count | 3 |
| Shaft Diameter | 2.19mm |
| Maximum Operating Temperature | 125°C |
| Length | 9.53mm |
| Standards/Approvals | RoHS |
| Height | 10.03mm |
| Depth | 4.83mm |
| Element Material | Cermet |
Product Details
Side Adjust 3296P Series
Bourns® 3296P 3/8″ Square Multiturn Cermet Trimming Potentiometer (Trimpot®)
Slim body profile – higher packing density
Sealed to withstand immersion board washing
Moulded body with built-in stand-offs
Large screw slot for easier adjustment
Wiper idles at end travel
Slim body profile-higher packing density
Sealed to withstand immersion board washing
Flame retardant plastic housing
Double chevron shaft seal
Moulded body with built in stand offs
IC style pins for PCB assembly
Precious metal wiper for set point stability
