ABB 1.6 MS/MO132 MCB Mini Circuit Breaker, 690 V | 1SAM340000R1006
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 11 pcs
Mfr. Part No: 1SAM340000R1006
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ABB |
| Current Rating | 1.6 |
| Range | MS/MO132 |
| Motor Protection Component | Circuit Breaker |
| Supply Voltage | 690 V |
| Overall Length | 86.75mm |
| Overall Width | 45mm |
| Overall Depth | 86.75mm |
| Minimum Operating Temperature | -25°C |
| Voltage Rating | 600 V ac |
| Maximum Operating Temperature | +70°C |
| Terminal Type | Screw |
| Number of Poles | 3 |
| Breaking Capacity | 100 kA |
| Enclosure Type | Din Rail |
Product Details
ABB MCB Mini Circuit Breaker, 1.6A Current Rating, 690V Supply Voltage – 1SAM340000R1006
This MCB mini circuit breaker by ABB is designed to provide efficient electrical circuit protection. With a compact 45mm width, it is ideal for protecting control transformers on the primary side. The circuit breaker offers fuse-less protection against overload and short-circuit, with a short-circuit current setting fixed at 20 times the rated operational current. Additionally, it features temperature compensation, a trip-free mechanism, and a lockable handle for added security.
Features & Benefits
• Compact design for space-saving installation
• Fuse-less protection against overload and short-circuit
• Short-circuit current setting at 20 times the rated operational current
• Temperature compensation for reliable performance
• Lockable handle to prevent unauthorised changes
• Fuse-less protection against overload and short-circuit
• Short-circuit current setting at 20 times the rated operational current
• Temperature compensation for reliable performance
• Lockable handle to prevent unauthorised changes
Applications
• Ideal for protecting control transformers on the primary side
• Suitable for residential electrical applications
• Suitable for residential electrical applications
Can it provide fuse-less protection against overload?
Yes, the MCB Mini Circuit Breaker offers fuse-less protection against overload and short-circuit.
Will it protect control transformers on the primary side?
Yes, this circuit breaker is specifically designed to protect control transformers on the primary side.
Is it suitable for residential circuit protection?
Yes, the MCB Mini Circuit Breaker is ideal for residential electrical applications due to its reliable performance.
