ABB 1 Phase LCD Energy Meter, Type Direct Connected | 2CMA100240R1000 A41 MON MBUS 80A
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: 2CMA100240R1000 A41 MON MBUS 80A
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ABB |
| Product Type | Energy Meter |
| Series | A41 |
| Display Type | LCD |
| Number of Digits | 4 |
| Cutout Height | 26.5mm |
| Cutout Width | 70mm |
| Number of Phases | 1 |
| Number of Outputs | 1 |
| Number of Inputs | 2 |
| Pulse Output | Yes |
| Digit Height | 85mm |
| Meter Accuracy | ±1 % |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | 70°C |
| Standards/Approvals | IEC 62053-21, EN 50470-1, EN 50470-3, IEC 62052-11 |
| Depth | 65mm |
| Meter Type | Direct Connected |
Product Details
ABB Energy Meter, 7 Counter Digits, 5A Current Rating – A41 Series – 2CMA100240R1000 A41 MON MBUS 80A
Stay in the loop about your system’s power use with this energy meter from ABB. It gives you an easy-to-read display of a circuit’s energy consumption, making it quick to check if your equipment’s running efficiently. A backlit LCD screen keeps you in the picture, even in dark or dimly lit areas. Mounting the device is done in a jiffy without special tools, as it fits onto a DIN rail. Support for M-bus communication sets it up to work with control devices, so it slips into your setup without a hitch. As the meter measures 70 (W) x 26.5 (H) x 65mm (L), it fits neatly into a standard enclosure.
Features & Benefits
• Durable PC housing for effective impact resistance
• Reading accuracy of ±1%, providing precise energy measurements
• Handles current up to 80A to keep up with intense electrical loads
• Easy push button interface for handy control
• Low power consumption of 0.807W, making for energy-efficient monitoring
Applications
• Industrial robotics
• Packaging industry
• Processing plants
Does this energy meter notify me if my equipment draws too much power?
Yes, this device supports up to 25 programmable alarms to automatically alert you to excessive energy use.
