ABB 1 Phase LCD Energy Meter, Type Direct Connected | 2CMA170503R1000 A41 MON MOD 80A SILVER M
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 9 pcs
Mfr. Part No: 2CMA170503R1000 A41 MON MOD 80A SILVER M
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ABB |
| Series | A41 |
| Product Type | Energy Meter |
| Display Type | LCD |
| Cutout Height | 97mm |
| Number of Digits | 4 |
| Cutout Width | 70mm |
| Number of Phases | 1 |
| Number of Outputs | 2 |
| Pulse Output | Yes |
| Number of Inputs | 2 |
| Digit Height | 85mm |
| Meter Accuracy | ±1 % |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | 70°C |
| Standards/Approvals | IEC |
| Depth | 65mm |
| Meter Type | Direct Connected |
Product Details
ABB Energy Meter, 4-Digit Display Configuration, 80A Current Rating – A41 Series – 2CMA170503R1000
Want to keep an eye on single-phase power use in your workplace? Get this energy meter from ABB on the case. It’s ideal for low-power tasks, thanks to its 57.7 to 288V voltage rating. A backlit LCD screen presents data clearly, making it easy to read in dimly lit areas. The unit’s direct meter type provides real-time measurements, which makes data monitoring and collecting hassle-free. Compact dimensions of 26.5 (H) x 70 (W) x 65mm (D) mean this meter won’t take up much space in your system.
Features & Benefits
• Performs reliably in challenging temperatures ranging between -40°C and +70°C
• DIN rail mounting makes installation straightforward
• Measures a frequency range between 50 and 60Hz, so handles demanding applications
• Light 0.246kg weight doesn’t add excess load to your setup
• Up to 25 event alarms signal specific faults, so you can make fix issues as soon as they pop up
Applications
• Industrial power supplies
• Factory automation
• Assembly lines
Does this meter have an IP rating?
Yes, it has an IP20 rating, which means it’s resistant to dust, as well as objects over 12mm in size, such as tools, fixings and your fingers.
