ABB 1P Pole Isolator Switch – 16A Maximum Current | 2CDD281101R0016 SD201/16
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: 2CDD281101R0016 SD201/16
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ABB |
| Number of Poles | 1P |
| Maximum Current | 16A |
| Voltage Rating | 60 V dc, 253V ac |
| Accepts Padlocks | Yes |
| Series | SD201 |
| Auxiliary Contacts Available | Yes |
| Normal State Configuration | NO |
| Range | Pro M Compact |
| Length | 17.5mm |
| Width | 69mm |
| Depth | 88mm |
| Throw Configuration | SPST |
| Terminal Type | Screw |
| Maximum Operating Temperature | +55°C |
| Minimum Operating Temperature | -25°C |
Product Details
ABB 1-Pole DIN Rail Switch Disconnector
The ABB SD 201 is a single-pole DIN rail switch disconnector. It is a pro-M compact series by a new range of switch disconnectors that provides state-of-the-art safety and comfort. It has a clear contact position indication in red/green colour. The laser printing and design of the device allow a consistent optical appearance in the distribution board. Its service temperature ranges between -25°C and 55°C.
Features and Benefits
• Accepts padlocks
• Captive screws with recessed head
• Compatibility with all the MCB accessories
• Consistent design to other System pro M DIN rail products
• Cross wiring with MCBs or RCDs using bus bars
• Durable device identification due to laser labelling
• Highest performance at an increased voltage level
• Maximum current is 16A
• Rated voltage is 60VDC and 253VAC
• Short-circuit current is 25 kA
• Captive screws with recessed head
• Compatibility with all the MCB accessories
• Consistent design to other System pro M DIN rail products
• Cross wiring with MCBs or RCDs using bus bars
• Durable device identification due to laser labelling
• Highest performance at an increased voltage level
• Maximum current is 16A
• Rated voltage is 60VDC and 253VAC
• Short-circuit current is 25 kA
Applications
• Electronic appliances
• Industrial appliances
• Power supplies
• Power tools
• Uninterruptible power supply
• Industrial appliances
• Power supplies
• Power tools
• Uninterruptible power supply
Certifications
• IEC/EN 60947-3
• IP20 rated
• IP40 rated
• IP20 rated
• IP40 rated
