ABB, 1SBN05 Surge Suppressor Unit 65V dc Maximum Voltage Rating Surge Suppressor | 1SBN050020R1001
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 15 pcs
Mfr. Part No: 1SBN050020R1001
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ABB |
| Product Type | Surge Suppressor Unit |
| Suppressor Type | Surge Suppressor |
| Maximum Voltage | 65V dc |
| Packaging | Blister 2 piece |
| Series | 1SBN05 |
| Minimum Operating Temperature | -20°C |
| Maximum Operating Temperature | 70°C |
| Length | 30.25mm |
| Height | 10.5mm |
| Depth | 32.4mm |
| Standards/Approvals | EU Directive 2002/95/EC |
| Hazardous Area Certification | No |
Product Details
1SBN050020R1001
The ABB RT5/65 is a transil diode surge suppressor designed to reduce the maximum overvoltage peak value and to limit or even completely eliminate the high pre-damping voltage frequencies, when used or with a DC operated conventional contactor for a rated control circuit voltage between 25 to 65 V DC.
It has very fast clipping
Operating temperature -20 to +70 °C
It has 30.25 x 10.5 x 32.4 mm dimensions
