ABB Jokab AFS Contactor, 100/250 V ac/dc Coil, 3-Pole, 30 A, 9 kW 24 V, 3 NO, 600V ac | 1SBL177082R1322 AFS16-30-22-13
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 8 pcs
Mfr. Part No: 1SBL177082R1322 AFS16-30-22-13
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ABB Jokab |
| Product Type | Contactor |
| Coil Voltage | 100/250 V ac/dc |
| Number of Poles | 3 |
| Contact Voltage | 600V ac |
| Contact Current | 30A |
| Series | AFS |
| Power Rating | 9kW |
| Mount Type | DIN Rail |
| Function | Safety |
| Normal State Configuration | 3 NO |
| Auxiliary Contact Configuration | 2 NO/2 NC |
| Number of Auxiliary Contacts | 4 |
| Terminal Type | Screw |
| Operational Current Ie | 16A |
| Contactor Application | Motor Control |
| Control Circuit Voltage Uc | 24 V |
| Minimum Operating Temperature | -40°C |
| Length | 45mm |
| Depth | 80mm |
| Standards/Approvals | cUL, CE, CSA, EAC, IEC, RoHS |
| Width | 110.5 mm |
| Pole and Throw Configuration | 3 |
Product Details
ABB Jokab Contactor, With Built-In Surge Protection, Screw Terminals – AFS Series – 1SBL177082R1322 AFS16-30-22-13
Looking for a switching component that goes the extra mile? Try this contactor from ABB Jokab. A maximum mechanical switching frequency of 3,600 cycles per hour offers lightning-fast performance, even when the unit’s feeling the pressure in systems carrying high currents. A yellow housing means the unit stands out in a crowd, for quick and easy identification on a busy circuit board. Built-in surge protection lets you save space and simplify your setup, as there’s no need for an additional protective device.
Features & Benefits
• Screw terminals offer quick and easy wiring using only a screwdriver
• Protective cover prevents unauthorised or accidental adjustment of the device, for safety
• Resists shock and vibration, so it’s compatible with harsh industrial environments
• IP20-rated terminals that are protected against touch and objects larger than 12mm
Applications
• Electric vehicles
• Lighting control systems
• Industrial automation
• Commercial buildings
What’s the voltage control range of this contactor?
A wide control voltage range between 100 and 250V DC makes this component just what you need to take the reins in circuits with large power variations.
