ABB Sensor Actuator Cable | 2TLA020056R4000 M12-C103

The Vital safety device from ABB is the heart of a new solution which makes it possible to install/connect many different types of safety device in the same safety circuit and still achieve safety category 4 in accordance with EN 954-1/EN ISO 13849-1. The Vital module is based upon a dynamic single-channel concept as opposed to conventional dual-channel safety relays. ABB have designed this unit to accommodate up to 30 dynamic sensors within the safety circuit which can be supervised by one Vital module. The Vital unit can therefore replace several safety relays. Safety components with output contacts can be connected to the Vital via low cost Tina adaptors. The Vital also has automatically or manually supervised reset selection, dual safety outputs, and an information output for reset indication and status information for PLC’s.

Cost-effective cable routing/connections

Information output with two functions

LED indication of: power supply, dynamic signal and outputs

Detachable connector blocks

Two NO safety outputs

Manually supervised or automatic reset

Can accommodate long cable lengths

Standard width: 22.5 mm

IP40 protection class rating

A mechanical life of >10⁷ operations

Safety category 4, according to EN 954-1/EN ISO 13849-1 dynamic safety circuit

Unused ports on the Tina 4A and 8A must be blanked by using a Tina 1A blanking plug.

UL, CSA
