ABB System Pro M Compact S300P Miniature Circuit Breaker, 1-Pole, 8 A, Type Z, 240 V ac AC, 72 V dc DC, 25 kA Breaking | 2CDS381001R0408
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 13 pcs
Mfr. Part No: 2CDS381001R0408
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ABB |
| Product Type | Miniature Circuit Breaker |
| Number of Poles | 1 |
| Current Rating | 8 A |
| Tripping Characteristics | Type Z |
| Rated AC Voltage | 240 V ac |
| Rated DC Voltage | 72 V dc |
| Breaking Capacity | 25kA |
| Mount Type | DIN Rail |
| Range | System Pro M Compact |
| Series | S300P |
| Terminal Type | Screw |
| IP Rating | IP20, IP40 |
| Depth | 69mm |
| Width | 17.5 mm |
| Standards/Approvals | IEC/EN 60947-2 IEC/EN 60898-1 UL 1077 CSA 22.2. No.235 GB/T 14048.2 GB/T 10963.1 |
| Height | 88mm |
Product Details
The ABB Miniature Circuit Breaker is designed to be used in installations where high breaking capacities are required to protect against short circuits and overloads. features an integrated trip indicator for clear on site signaling of tripping events and a dual DIN Rail release for quick, easy installation. It is fully compatible with the System pro M compact accessory range, supporting numerous functions. Additionally, it offers quick product identification via a QR code, granting direct access to the ABB product database.
High short circuit breaking capacity provides supreme protection
Advanced tripping characteristics enhance operational safety
Terminals equipped with fail safe feature to avoid improper installation
Certified quality and compliance according to worldwide product standards
IP40 protection rating in enclosure with cover
