ABB, Tmax XT, 1SDA06 Molded Case Circuit Breaker 3-Pole 40 A, Breaking Capacity 4 kA, Fixed | 1SDA067412R1 XT1N 160 TMD 40A FF
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 6 pcs
Mfr. Part No: 1SDA067412R1 XT1N 160 TMD 40A FF
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ABB |
| Product Type | Molded Case Circuit Breaker |
| Range | Tmax XT |
| Series | 1SDA06 |
| Number of Poles | 3 |
| Current Rating | 40 A |
| Breaking Capacity | 4kA |
| Mount Type | Fixed |
| Rated AC Voltage | 690 V |
| Rated DC Voltage | 500 V |
| Terminal Type | Screw |
| Height | 130mm |
| Depth | 70mm |
| Standards/Approvals | IEC |
| Width | 76.2 mm |
| Break Time | Instantaneous |
Product Details
The ABB Moulded case circuit breaker Tmax XT1N comes with 3 poles. It has front terminals and thermomagnetic release type. It comes with rated uninterrupted current of 160A.
Rated current (In):40 A
Rated frequency (f): 50/60 Hz
Rated voltage (Ur): 690 V
Rated impulse withstand voltage (Uimp): 8 kV
