ABB, XT4S, XT4S Molded Case Circuit Breaker 4-Pole 160 A, Breaking Capacity 85 kA, Fixed | 1SDA068323R1 XT4S 160 TMA 160A 3P+N FF
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: 1SDA068323R1 XT4S 160 TMA 160A 3P+N FF
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ABB |
| Product Type | Molded Case Circuit Breaker |
| Range | XT4S |
| Series | XT4S |
| Number of Poles | 4 |
| Current Rating | 160 A |
| Breaking Capacity | 85kA |
| Rated AC Voltage | 690 V ac |
| Mount Type | Fixed |
| Rated DC Voltage | 500 V dc |
| Terminal Type | Fixed |
| Depth | 82.5mm |
| Height | 160mm |
| Standards/Approvals | CE, IEC, RoHS |
| Width | 140 mm |
| Better World Product | Yes |
| Better World Claim | Designed for Disassembly |
| Reset Actuator Type | Lever |
| Tripping Mechanism | Thermal Magnetic |
Product Details
The ABB XT4S fixed 4-pole power distribution circuit-breaker has front terminals and thermomagnetic release. This circuit breaker has 690 V rated voltage and 160 A rated uninterrupted current (Iu).
800 to 1600 A rated instantaneous short circuit current setting (Ii)
Short circuit performance level: S
Neutral = 50% phase
