Allen Bradley 1 Button Touch Button, 800Z Series | 800Z-GF2065
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 4 pcs
Mfr. Part No: 800Z-GF2065
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Allen Bradley |
| Product Type | Touch Button |
| Series | 800Z |
| Contact Configuration | SPDT |
| Number of Push Buttons | 1 |
| Push Button Actuation | Momentary |
| Housing Material | Polyethylene Terephthalate, Polybutylene Terephthalate |
| IP Rating | IP66 |
| Width | 40.9 mm |
| Depth | 48.3mm |
| Length | 69.9mm |
| Standards/Approvals | No |
Product Details
Zero Force Touch Buttons
Black polysulfone (VALOX 357) thermoplastic housing
Suitable for single or two hand control applications
Fits 22.5mm hole
Prewired or five-pin micro quick disconnect connector versions available
Reduces the risk of repetitive strain injuries
Ergonomic design for simple and easy operation
CE Marked
IP66 ingress protection
1200 psi hose down capability
A 30.5mm to 22.5mm hole adaptor is available separately
Zero Force & Opto Touch Switches
Actuated by sensors using patented Field Effect Technology which converts the touch of the operators hand into an electrical output. The two sensors have to be touched within 0.2 seconds of each other and can differentiate between a person’s hand and most solid objects/substances, as well as resistance to accidental actuation via clothing, fluid, splashes etc.,There are built in diagnostic safeguards for power-up protection, foreign object intervention and film/deposit interference which all result in LED indication.
Approvals
UL/ UL listed for Canada
