Allen Bradley 836P Series Pressure Sensor, 4 → 20 mA, Analogue, PNP-NO/NC Output, Relative Reading | 836P-D2NMAA30PA-D4

Allen-Bradley 836P series solid-state pressure sensors are capable of measuring pressure of liquid or gases in a rugged, compact housing. The 836P sensors feature embedded IO-Link 1.1 communication protocol, which allows for easy integration while delivering data directly into a control system in an easy-to-use manner.

With a rotatable housing (320°) and head (330°), the flexible 836P display model accommodates the most space-critical applications. And for even greater adjustability, the large visual LED display can be rotated 180º. Additional features include pressure ranges from -1…551 bar (-14.5 psi to 8000 psi), tactile push buttons for easy setup, and an IP67 enclosure rating. 836P sensors have dual PNP or one PNP + one 4 mA to 20 mA output configurations in gauge, absolute or vacuum pressure measurement types with a large selection of process connections.

Corrosion resistant 316L stainless steel sensing element

Compact form factor

LED display

IP67 rated

Rotatable housing and head

Available in various process connections

IO-Link communication protocol

Use this Allen Bradley solid-state pressure sensor from Rockwell Automation to maintain fluid pressure in your system. It uses a PNP transistor to perform switching functions reliably. The easy-to-use unit has an LED display for quick status reading and three navigation buttons, so you can easily set switching points, reset points and switching delays. Its head and body can be rotated to suit the needs of your system. Thanks to its stainless steel housing, this device is corrosion resistant and can be used safely in humid environments.

• IP67 rating means this device is dust-proof and can handle immersion in water of 1m for 30 minutes
• Operating temperature range between -20°C and +80°C for use in harsh conditions
• Pressure range between 0 and 20 bar for use in heavy-duty applications
• 1/4 NPT threading for a secure and vibration-proof connection

• CE conformity – Pressure equipment directive 97/23/EC
• cULus
• EN 61340-5-1:2007
• ANSI/ESD S20.20:2014

This rating is used to interpret the potential pressure level in your vessel at between 0% and 100%.
