Allen Bradley Bulletin 2080 Series Logic Controller for Use with Micro 820 Series, Relay Output, 12-Input, Digital Input | 2080-LC20-20QBBR
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 7 pcs
Mfr. Part No: 2080-LC20-20QBBR
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Allen Bradley |
| Manufacturer Series | Bulletin 2080 |
| Number of Inputs | 12 |
| Output Type | Relay |
| For Use With | Micro 820 Series |
| Input Type | Digital |
| Number of Digital Inputs | 20 |
| Voltage Category | 24 V dc |
| Number of Outputs | 8 |
| Number of Digital Outputs | 20 |
| Kit Included | Yes |
| Output Current | 1 A |
| Maximum Operating Temperature | +65°C |
| Dimensions | 100 x 80 x 90 mm |
| Depth | 90mm |
| Program Capacity | 10 kB |
| Communication Port Type | RS-232, RS-485 |
| Number of Communication Ports | 1 |
| Programming Language Used | Function Block, Ladder Logic, Structured Text |
| Mounting Type | DIN Rail |
| Width | 80mm |
| Length | 100mm |
| Minimum Operating Temperature | -20°C |
Product Details
Our Micro820® Programmable Logic Controller Systems include a nano-sized footprint and are designed for small standalone machine control and remote automation applications that require flexible communications and I/O capabilities. These controllers support up to 36 I/O points with many embedded features such as Ethernet, microSD slot for recipe and data log, and analogue I/O.
Offers 20-point controllers
Provides embedded 0…10V non-isolated 4 channel analog input and 1 channel analog output for speed control of an AC drive
Provides embedded communications via non-isolated serial port (for RS-232 and RS-485 communications) and Ethernet port
Communicates via EtherNet/IP™
Provides embedded support for up to four 10k thermistor temperature inputs
Supports program download through USB with an optional 3.5-in. Remote LCD
Supports up to two Micro800™ Plug-in Modules
Supports microSD™ card for program transfer, datalog, and recipe management
Applications
Air handling unit
Pump control with SMS plug-in
Provides embedded 0…10V non-isolated 4 channel analog input and 1 channel analog output for speed control of an AC drive
Provides embedded communications via non-isolated serial port (for RS-232 and RS-485 communications) and Ethernet port
Communicates via EtherNet/IP™
Provides embedded support for up to four 10k thermistor temperature inputs
Supports program download through USB with an optional 3.5-in. Remote LCD
Supports up to two Micro800™ Plug-in Modules
Supports microSD™ card for program transfer, datalog, and recipe management
Applications
Air handling unit
Pump control with SMS plug-in
