Allen Bradley Inductive Rectangular Proximity Sensor, 10 mm Detection, PNP NO+NC, 24 → 30 V dc | 871FM-MV10BA30-FD02X
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 8 pcs
Mfr. Part No: 871FM-MV10BA30-FD02X
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Allen Bradley |
| Sensor Technology | Inductive |
| Detection Range | 10 mm |
| Body Style | Rectangular |
| Output Function | NO+NC |
| Digital Switching Output Type | PNP |
| Connection Type | M12 |
| Supply Voltage | 24 → 30 V dc |
| Length | 52mm |
| IP Rating | IP67 |
| Mounting Type | Flush |
| Maximum DC Voltage | 30V |
| Minimum Operating Temperature | -25°C |
| Shielding | Shielded |
| Maximum Switching Frequency | 50Hz |
| Switching Current | 200 mA |
| Depth | 14mm |
| Communication Protocol | IO-LINK |
| Switching Frequency | 50 Hz |
| Series | 871FM |
Product Details
The Allen Bradley sensors are designed to sense the presence of ferrous and nonferrous metal objects without touching them at equal sensing range. The 871FM is offered in general purpose and rugged welding versions with sensing ranges up to 10 mm.
Dimensions 30 x 52 x 40 mm
Nominal sensing distance 10 mm
Shielded
Connector type PVC pigtail, DC micro QD, 4-pin
Nominal sensing distance 10 mm
Shielded
Connector type PVC pigtail, DC micro QD, 4-pin
