APDS-9007-020 Broadcom Ambient Light Sensor Chip LED 6 | APDS-9007-020
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 6 pcs
Mfr. Part No: APDS-9007-020
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Broadcom |
| Product Type | Ambient Light Sensor |
| Typical Rise Time | 200μs |
| Mount Type | Surface |
| Typical Fall Time | 200μs |
| Package Type | Chip LED |
| Minimum Supply Voltage | 2V |
| Maximum Supply Voltage | 3.6V |
| Application | Digital Camera, Webpads, Mobile Phone, PDA, TV |
| Output Signal Type | Current, Analogue |
| Minimum Operating Temperature | -40°C |
| Number of Pins | 6 |
| Height | 0.8mm |
| Length | 2.4mm |
| Width | 2 mm |
| Series | APDS-9007 |
| Standards/Approvals | RoHS Compliance |
| Maximum Operating Temperature | 85°C |
| Automotive Standard | No |
Product Details
The Broadcom APDS series is a low cost analog-output ambient light photo sensor in miniature chipLED lead-free surface mount package. This device provides a Logarithmic response over a wide dynamic range of 3 lux to 70K lux and has a low sensitivity variation across various light sources. It is well suited for applications that operates under high ambient brightness.
Spectral responsivity close to that of human eye
Low sensitivity variation across various light sources
Lead-free package
RoHS compliance
