APDS-9306-065 Broadcom Ambient Light Sensor 560 nm Chip LED 6 | APDS-9306-065
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 9 pcs
Mfr. Part No: APDS-9306-065
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Broadcom |
| Product Type | Ambient Light Sensor |
| Typical Rise Time | 300ns |
| Mount Type | Surface |
| Typical Fall Time | 300ns |
| Package Type | Chip LED |
| Maximum Wavelength Detected | 560nm |
| Minimum Supply Voltage | 1.7V |
| Maximum Supply Voltage | 3.6V |
| Application | PDA |
| Number of Pins | 6 |
| Minimum Operating Temperature | -45°C |
| Output Signal Type | I2C |
| Standards/Approvals | UL |
| Length | 2mm |
| Series | APDS |
| Height | 0.34mm |
| Width | 2 mm |
| Maximum Operating Temperature | 85°C |
| Automotive Standard | No |
Product Details
The Broadcom /APDS-9306-065 is a low voltage Digital Ambient Light Sensor that converts light intensity to digital signal output with I2C interface. It consists of photodiode, ADC, oscillator and power-on reset to ensure consistent start-up. ADCs convert the photodiode currents to a digital output and the device is capable of rejecting50Hz and 60Hz fl icker caused by artifice cial light sources.
Utilizes Coating Technology to Emulate Human Eye
Spectral Response
High Sensitivity in Low Lux Condition – Ideally Suited for Operation Behind Dark Glass
Wide Dynamic Range 18,000,000 : 1
Low Lux Performance 0.01 lux
Up to 20-Bit Resolution
Wide Power Supply Range
