Arcol Ohmite 1 GΩ Thick Film Resistor 1.5 W 1 % SM104031007FE | SM104031007FE
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 9 pcs
Mfr. Part No: SM104031007FE
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Arcol Ohmite |
| Resistance | 1GΩ |
| Product Type | Resistor |
| Resistor Type | Thick Film |
| Power Rating | 1.5W |
| Tolerance ± | 1% |
| Voltage | 10 kV |
| Axial/Radial | Radial |
| Technology | Thick Film |
| Series | Slim Mox |
| Automotive Standard | No |
| Minimum Operating Temperature | -55°C |
| Lead Pitch Radial | 22.86mm |
| Maximum Operating Temperature | 110°C |
| Height | 8.64mm |
| Standards/Approvals | RoHS |
| Width | 2.54 mm |
| Length | 27.43mm |
| Temperature Coefficient | +25 ppm/°C |
| Lead Diameter | 0.81mm |
Product Details
Ohmite Slim-MOX Series Precision Thick Film Resistors
Ohmite Slim-MOX series precision thick film resistors provide stable performance for a wide range of resistance values, with voltage ratings up to 25K. Low temperature coefficients are available for high stability circuit applications. The space-saving Planar package offers an alternative to traditional high-voltage resistors.
Features & Benefits:
High dielectric and low outgassing epoxy coating
Low resistor noise
Non-inductive
RoHS compliant
Radial terminals
