Assemtech SPST PCB Reed Switch 0.5 A 140 V | GC2522 Kit
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 9 pcs
Mfr. Part No: GC2522 Kit
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Assemtech |
| Product Type | Reed Switch |
| Contact Configuration | SPST |
| Maximum Switching Current | 0.5A |
| Maximum Switching Power | 6VA |
| Maximum Switching Voltage | 140V |
| Contact Resistance | 150mΩ |
| Contact Material | Rhodium |
| Maximum Release Time | 0.05ms |
| Operating Time Including Bounce | 0.3ms |
| Terminal Type | Wire |
| AT Value Range | 30 to 40 AT |
| Mount Type | PCB |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | 125°C |
| Width | 2.1 mm |
| Length | 11mm |
| Standards/Approvals | ISO |
| Series | GC |
Product Details
Form A & C Reed Switch Kits
These kits have been specially brought together for the design stage. Each kit has a selection of sensitivity levels from the required series allowing you to test which is best for your application. This eliminates the need to purchase packs of each sensitivity helping to reduce waste and cost.
They are hermetically sealed in a gas-filled glass envelope. Actuation is done with an electro-magnet, a permanent magnet or a combination of both. If you prefer, they can be placed alongside a coil and actuated when a current is applied to the coil. They feature single pole, single throw, normally open contacts and have two magnetically actuated reeds.
Features
Hermetically sealed
Form A (SPNO) or form C (SPCO) ruthenium or rhodium plated contacts
Mechanical Life 10⁸ Operations
For suitable magnets, see stk. no 362-2401 typically
