BALLUFF Background Suppression Photoelectric Sensor, Block Sensor, 200 mm → 2 m Detection Range | BOS 50K-PA-RH12-S4
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 12 pcs
Mfr. Part No: BOS 50K-PA-RH12-S4
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | BALLUFF |
| Sensor Style | Block |
| Detection Type | Background Suppression |
| Detection Range | 200 mm → 2 m |
| Output Type | PNP |
| Electrical Connection | M12 Connector |
| Maximum DC Voltage | 30V |
| Terminal Type | Connector |
| Light Source | LED |
| IP Rating | IP67 |
| Maximum Current | 100 mA |
| Response Time | 1 ms |
| Minimum Operating Temperature | -10°C |
| Mounting Type | Panel Mount |
| Housing Material | ABS, PC |
| Series | BOS 50K |
| Maximum Operating Temperature | +60°C |
| Standards Met | CE, cULus |
Product Details
BOS Diffuse Proximity Rectangular Sensors
The photoelectric sensors from BALLUFF BOS range use diffuse proximity technology to detect if an object moves within the sensing range. The sensor emits a light beam which reflects of the object in its path, when the object moves within the sensing range the light will reflect back at the correct angle to hit the receiver unit triggering activation of the sensor. Diffuse photoelectric sensors are used in industrial environments for applications where accurate proximity detection of metal or non-mental objects is essential.
Pre cabled or connector
Rectangular body
3 wire and 4 wire DC configuration
Short-circuit protected
Polarity reversal protected
Rectangular body
3 wire and 4 wire DC configuration
Short-circuit protected
Polarity reversal protected
