BALLUFF Cable Cylinder Magnetic Sensor, IP67 30 V, BMF00LH LED Indicator | BMF00LH
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 12 pcs
Mfr. Part No: BMF00LH
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | BALLUFF |
| Product Type | Cylinder Magnetic Sensor |
| Output Function | Switching output |
| Series | BMF00LH |
| Housing Material | Polyamide 12 |
| LED Indicator | Yes |
| Voltage | 30 V |
| For Use With | Short-Stroke Cylinders |
| IP Rating | IP67 |
| Switching Action | No, PNP |
| Measurement Principle | Magnetic Field Sensor |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | 85°C |
| Depth | 2.9mm |
| Height | 16.8mm |
| Hazardous Area Certification | CE, cULus, WEEE, EAC |
| Width | 4.5 mm |
| Diameter | 2.5 mm |
| Standards/Approvals | CE, EAC, WEEE, IEC 60947-5-2, UL |
| Electrical Connection Type | Cable |
Product Details
The BMF magnetic field sensors for T-slots can be mounted directly in the groove and distinguish themselves with their particularly strong hold. They can be mounted flush so that they are suitable for space-critical applications. In addition, Balluff offers extremely short configurations for flexible usage options. The sensors detect the piston position without contact through the cylinder walls. The system is adaptable for cylinders and grippers with both strong and weak magnets.
Dimension 16.8 x 2.9 x 4.5 mm
Connection M8x1-Male, 3-pin
Application Optimized response path especially suited for short-stroke cylinders.
