BALLUFF Cable Cylinder Magnetic Sensor, IP67 30 V LED Indicator | BMF0058
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 7 pcs
Mfr. Part No: BMF0058
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | BALLUFF |
| Product Type | Cylinder Magnetic Sensor |
| Output Function | Switching output |
| Housing Material | Liquid Crystal Polymer |
| LED Indicator | Yes |
| Voltage | 30 V |
| For Use With | Larger Actuators |
| IP Rating | IP67 |
| Switching Action | PNP, No |
| Measurement Principle | Magnetic Field Sensor |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | 85°C |
| Standards/Approvals | IEC 60947-5-2, UL, EAC, CE, WEEE |
| Depth | 5mm |
| Diameter | 2.9 mm |
| Height | 33.5mm |
| Width | 10.5 mm |
| Hazardous Area Certification | No |
| Electrical Connection Type | Cable |
Product Details
The BALLUFF magnetic field sensors with flexible attachment systems are suitable for all groove shapes, such as T-, C-, round, or trapezoidal slots. It can be adapted to almost all cylinder types using special manufacturer-specific mounting brackets. As a result, a reliable tool is always available for detecting position on grippers and pneumatic cylinders. The main thing is that it is very flexible. Moreover, the switch point is adjusted only once and is retained even if the sensor is replaced. This way you increase the functional reliability of your equipment by making sensor replacement safer and easier, even in hard-to-reach places. Our universally applicable sensor models save you storage space and can reduce your costs.
Dimension 33.5 x 5 x 10.5 mm
Connection M12x1-Male, 4-pin, A-coded
Application miniaturized larger actuators
