BALLUFF Capacitive Block Proximity Sensor, 8 mm Detection, PNP NO, 12 → 30 V dc | BCS R08RRE-PSM80C-EP00,3-GS75
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 10 pcs
Mfr. Part No: BCS R08RRE-PSM80C-EP00,3-GS75
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | BALLUFF |
| Sensor Technology | Capacitive |
| Detection Range | 8 mm |
| Body Style | Block |
| Digital Switching Output Type | PNP |
| Output Function | NO |
| Cable Length | 0.3m |
| Connection Type | Pre-Cabled |
| Supply Voltage | 12 → 30 V dc |
| Length | 34mm |
| IP Rating | IP67 |
| Mounting Type | Flush |
| Housing Material | PP |
| Width | 16mm |
| Maximum DC Voltage | 30V |
| Minimum Operating Temperature | -25°C |
| Shielding | Shielded |
| Switching Current | 50 mA |
| Maximum Switching Frequency | 50Hz |
| Maximum Operating Temperature | +70°C |
| Switching Frequency | 50 Hz |
| Standards Met | CE, cULus Listed |
| Series | R08 |
| Reverse Polarity Protection | Yes |
| Short Circuit Overload Protection | Yes |
| Depth | 8mm |
Product Details
BCS DC 3 Wire Flush Micro Box Capacitive Sensors
BCS capacitive sensors monitor and detect stack heights and levels as well as the presence of objects and content in glass, plastic or paper packages all with extreme precision. The BCS range are unaffected by dust, surface reflections or any object composition such as colour or texture. Capacitive sensors can also detect levels of solids or liquids with reliability through glass and plastic walls. This diverse series consists of high temperature and pressure ratings with stainless steel and PTFE housings for harsh environments.
Flush
DC 3 wire and DC 3 wire smart technology
Level and object detection
Block housing
Variety of housing sizes
Cable
Led
IP67
DC 3 wire and DC 3 wire smart technology
Level and object detection
Block housing
Variety of housing sizes
Cable
Led
IP67
Approvals
IP 67
