BALLUFF Capacitive Threaded Barrel Proximity Sensor, M12, 4 mm Detection, PNP/NPN NO/NC | BCS M12T4D-XXS40C-EP02-GZ01-002
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 7 pcs
Mfr. Part No: BCS M12T4D-XXS40C-EP02-GZ01-002
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | BALLUFF |
| Thread Size | M12 |
| Sensor Technology | Capacitive |
| Body Style | Threaded Barrel |
| Detection Range | 4 mm |
| Output Function | NO/NC |
| Digital Switching Output Type | PNP/NPN |
| Length | 30mm |
| IP Rating | IP67 |
| Mounting Type | Non-Flush |
| Housing Material | Stainless Steel |
| Maximum DC Voltage | 8V |
| Minimum Operating Temperature | -30°C |
| Shielding | Unshielded |
| Maximum Switching Frequency | 100Hz |
| Switching Frequency | 100 Hz |
| Standards Met | CE |
| Maximum Operating Temperature | +80°C |
| Series | M12 |
Product Details
BCS DC 3 Wire Tubular Capacitive Sensor
BCS capacitive sensors monitor and detect stack heights and levels as well as the presence of objects and content in glass, plastic or paper packages all with extreme precision. The BCS range are unaffected by dust, surface reflections or any object composition such as colour or texture. Capacitive sensors can also detect levels of solids or liquids with reliability through glass and plastic walls. This diverse series consists of high temperature and pressure ratings with stainless steel and PTFE housings for harsh environments.
Flush and non flush
DC 3 wire
Tubular housing
Variety of housing sizes
Cable, connector
Led
IP67
DC 3 wire
Tubular housing
Variety of housing sizes
Cable, connector
Led
IP67
Approvals
IP 67
