BALLUFF Capacitive Threaded Barrel Proximity Sensor, M30, 25 mm Detection, PNP NO, 10 → 30 V dc | BCS M30B4E2-PSC25H-S04K
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 9 pcs
Mfr. Part No: BCS M30B4E2-PSC25H-S04K
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | BALLUFF |
| Thread Size | M30 |
| Sensor Technology | Capacitive |
| Body Style | Threaded Barrel |
| Detection Range | 25 mm |
| Output Function | NO |
| Digital Switching Output Type | PNP |
| Connection Type | M12 |
| Supply Voltage | 10 → 30 V dc |
| Length | 78.5mm |
| IP Rating | IP67 |
| Mounting Type | Non-Flush |
| Housing Material | Stainless Steel |
| Maximum DC Voltage | 30V |
| Minimum Operating Temperature | -25°C |
| Short Circuit Overload Protection | Yes |
| Standards Met | CE, cULus Listed |
| Switching Frequency | 100 Hz |
| Reverse Polarity Protection | Yes |
| Series | M30 |
| Maximum Switching Frequency | 100Hz |
| Shielding | Unshielded |
| Maximum Operating Temperature | +85°C |
| Switching Current | 100 mA |
Product Details
BCS DC 3 Wire Non Flush Cylinder Global Capacitive Sensors
BCS capacitive sensors monitor and detect stack heights and levels as well as the presence of objects and content in glass, plastic or paper packages all with extreme precision. The BCS range are unaffected by dust, surface reflections or any object composition such as colour or texture. Capacitive sensors can also detect levels of solids or liquids with reliability through glass and plastic walls. This diverse series consists of high temperature and pressure ratings with stainless steel and PTFE housings for harsh environments.
DC3 wire
Cylinder design
Short circuit protected
Polarity reversal
Level detection
M12, M18, M30
LED
IP67
Cylinder design
Short circuit protected
Polarity reversal
Level detection
M12, M18, M30
LED
IP67
