BALLUFF Circular Connector, 4 Contacts, Cable, M12 Connector, Socket, Female, IP67, BCC M435 Series | BCC0FJM

Name: BALLUFF Circular Connector, 4 Contacts, Cable, M12 Connector, Socket, Female, IP67, BCC M435 Series | BCC0FJM
SKU: 8900-242
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 3 pcs

Mfr. Part No: BCC0FJM

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 8900-242 Categories: BALLUFF, Industrial Circular Connectors

Description

Specifications

Attribute	Value
Brand	BALLUFF
Product Type	Circular Connector
Number of Contacts	4
Mount Type	Cable
Connector Size	M12
Current	4A
Plug/Socket	Socket
Contact Gender	Female
IP Rating	IP67
Orientation	Straight
Series	BCC M435
Coding	A
Voltage	250 V ac, 250 V dc
Termination Type	Screw
Minimum Operating Temperature	-40°C
Mating Type	Threaded
Maximum Operating Temperature	85°C
Housing Material	Polyamide Brass
Standards/Approvals	CE EAC WEEE
Contact Material	Brass

Product Details

The Balluff field attachable connector is used for the secure transmission of signals, data and power. It has M12x1-female, straight, 5-pin, A-coded connection with 4 connectable contacts and 4.0 A rated current (at 40 °C).

IDC wire mounting

0.34 to 0.75 mm² connection cross-section

4 to 8 mm cable diameter D

250 VDC / 250 VAC Operating voltage Ub

IP67 protection rating

-40 °C to 85 °C ambient temperature

CE, EAC, WEEE Approval/Conformity
