BALLUFF Circular Connector, 4 Contacts, Cable, M8 Connector, Plug, IP67, BKS-S218-RT14 Series | BCC02HH
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: BCC02HH
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | BALLUFF |
| Number of Contacts | 4 |
| Product Type | Circular Connector |
| Mount Type | Cable |
| Connector Size | M8 |
| Current | 4A |
| Plug/Socket | Plug |
| IP Rating | IP67 |
| Orientation | Straight |
| Series | BKS-S218-RT14 |
| Voltage | 32 V ac, 32 V dc |
| Coding | A |
| Termination Type | Screw |
| Minimum Operating Temperature | -40°C |
| Mating Type | Threaded |
| Maximum Operating Temperature | 85°C |
| Housing Material | Die Cast, Polyamide Zinc |
| Standards/Approvals | cURus, EAC WEEE |
| Contact Material | Copper Alloy |
Product Details
The Balluff field attachable connector is used for the secure transmission of signals, data and power. It has M8x1-male, Straight, 4-pin, A-coded connection with 4 connectable contacts and 4.0 A rated current (at 40 °C).
0.14 to 0.34 mm² Connection cross-section
2.5 to 5.4 mm Cable diameter D
IDC wire mounting
32 VDC / 32 VAC Operating voltage Ub
IP67 protection rating
-40 to 85 °C ambient temperature
cURus, EAC, WEEE Approval/Conformity
