BALLUFF Circular Connector, 5 Contacts, Cable, 7/8 in Connector, Socket, Female, IP67, BCC A345 Series | BCC0FK2

Name: BALLUFF Circular Connector, 5 Contacts, Cable, 7/8 in Connector, Socket, Female, IP67, BCC A345 Series | BCC0FK2
SKU: 0010-242
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 8 pcs

Mfr. Part No: BCC0FK2

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 0010-242 Categories: BALLUFF, Industrial Circular Connectors

Description

Specifications

Attribute	Value
Brand	BALLUFF
Product Type	Circular Connector
Number of Contacts	5
Mount Type	Cable
Current	12A
Connector Size	7/8 in
Plug/Socket	Socket
Contact Gender	Female
IP Rating	IP67
Orientation	Right Angle
Series	BCC A345
Voltage	600 V ac, 600 V dc
Minimum Operating Temperature	-25°C
Mating Type	Threaded
Termination Type	Screw
Maximum Operating Temperature	85°C
Housing Material	Die Cast Zinc
Standards/Approvals	CE, cURus, EAC, WEEE
Contact Material	Brass

Product Details

The Balluff field attachable connector is used for the secure transmission of signals, data and power. It has 7/8″-16 UN-female, angled, 5-pin connection with 5 connectable contacts and 12.0 A rated current (at 40 °C).

Screw terminals wire mounting

1.50 mm² connection cross-section

8 to 10 mm cable diameter D

600 VDC / 600 VAC Operating voltage Ub

IP67 protection rating

-25 °C to 85 °C ambient temperature

CE, cURus, EAC, WEEE Approval/Conformity
