BALLUFF Female 4 way Straight to Male 4 way Straight Sensor Actuator Cable, 2 m | BCC03CF
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 13 pcs
Mfr. Part No: BCC03CF
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | BALLUFF |
| Series | BCC03 |
| Product Type | Sensor Actuator Cable |
| Jacket Material | Polyvinyl Chloride |
| Jacket Colour | Grey |
| Cable Length | 2m |
| Connector Type A | Straight |
| Connector Gender A | Female |
| Number of Contacts A | 4 |
| Number of Contacts B | 4 |
| Connector Gender B | Male |
| Connector Type B | Straight |
| Voltage | 250 V |
| IP Rating | IP67, IP68, IP69K |
| Standards/Approvals | CE, cULus, EAC, RoHS, WEEE |
Product Details
The Balluff robust double-ended cordset is used for signals, data and power transmission continuously and securely. It is a PVC grey, 2 m, drag chain compatible cable having M12x1-female, straight, 5-pin, A-coded connection and M12x1-male, straight, 4-pin
-40 °C to 105 °C cable temperature at fixed routing
-5 °C to 105 °C cable temperature at flexible routing
250 VDC / 250 VAC Operating voltage Ub
IP67, IP68, IP69K/IP67, IP68, IP69K protection rating for both connections
CE, cULus, EAC, WEEE Approval/Confo
