BALLUFF Female 4 way Straight to Unterminated 4 way Unterminated Sensor Actuator Cable, 10 m | BCC02MA
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 9 pcs
Mfr. Part No: BCC02MA
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | BALLUFF |
| Product Type | Sensor Actuator Cable |
| Series | BCC02 |
| Jacket Colour | Black |
| Jacket Material | Polyurethane |
| Cable Length | 10m |
| Connector Type A | Straight |
| Number of Contacts A | 4 |
| Connector Gender A | Female |
| Connector Gender B | Unterminated |
| Connector Type B | Unterminated |
| Number of Contacts B | 4 |
| Voltage | 250 V |
| IP Rating | IP67, IP69K |
| Standards/Approvals | CE, cULus, EAC, RoHS, WEEE |
Product Details
The Balluff single-ended cordset is used for signals, data and power transmission. It is a PUR black, 10m, drag chain compatible cable having M8x1-female, straight, 3-pin, A-coded connection with 3 conductors and 4.0 A rated current (at 40 °C).
0.34 mm² Conductor cross-section
-50 °C to 90 °C cable temperature at fixed routing
-25 °C to 90 °C cable temperature at flexible routing
60 VDC / 60 VAC Operating voltage Ub
IP67, IP69K protection rating
CE, cULus, EAC, WEEE Approval/Conformity
