BALLUFF Inductive Block Proximity Sensor, 1.5 mm Detection, PNP NO, 10 → 30 V dc | BES R04KC-PSC15B-EV02
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 12 pcs
Mfr. Part No: BES R04KC-PSC15B-EV02
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | BALLUFF |
| Sensor Technology | Inductive |
| Detection Range | 1.5 mm |
| Body Style | Block |
| Digital Switching Output Type | PNP |
| Output Function | NO |
| Connection Type | Pre-Cabled |
| Cable Length | 2m |
| Supply Voltage | 10 → 30 V dc |
| IP Rating | IP67 |
| Length | 8mm |
| Mounting Type | Flush |
| Housing Material | Polyamide |
| Width | 16mm |
| Maximum DC Voltage | 30V |
| Minimum Operating Temperature | -25°C |
| Short Circuit Overload Protection | Yes |
| Switching Current | 100 mA |
| Depth | 4.7mm |
| Reverse Polarity Protection | Yes |
| Maximum Switching Frequency | 2.5kHz |
| Shielding | Unshielded |
| Standards Met | CE, cULus, IEC 60947-5-2 |
| Switching Frequency | 2.5 kHz |
| Maximum Operating Temperature | +70°C |
Product Details
BES R04 Small Design Inductive Sensors
Proximity switch in rectangular housing
Can be installed flush
LED display for switching status
Can be installed flush
LED display for switching status
Approvals
CE, UL
Block Style
Flush mounting, embeddable sensors with IP67 protection and an operating temperature range of -25 to +75°C. All have short circuit and reverse polarity protection and provide an LED indication of the on/off status.
