BALLUFF Inductive Threaded Barrel Proximity Sensor, M18, 8 mm Detection, PNP NO, 10 → 30 V dc | BES M18MD-PSC80B-BP02-003
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 6 pcs
Mfr. Part No: BES M18MD-PSC80B-BP02-003
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | BALLUFF |
| Thread Size | M18 |
| Sensor Technology | Inductive |
| Body Style | Threaded Barrel |
| Detection Range | 8 mm |
| Digital Switching Output Type | PNP |
| Output Function | NO |
| Connection Type | Pre-Cabled |
| Cable Length | 2m |
| Supply Voltage | 10 → 30 V dc |
| Length | 36mm |
| IP Rating | IP67 |
| Mounting Type | Flush |
| Housing Material | Brass |
| Maximum DC Voltage | 30V |
| Minimum Operating Temperature | -25°C |
| Switching Current | 130 mA |
| Maximum Switching Frequency | 150Hz |
| Shielding | Shielded |
| Switching Frequency | 150 Hz |
| Short Circuit Overload Protection | Yes |
| Maximum Operating Temperature | +70°C |
| Standards Met | CE, cULus, IEC 60947-5-2 |
| Reverse Polarity Protection | Yes |
Product Details
BES 3 / 4Wire M18 Inductive Proximity Sensor
This range of M18 cylindrical inductive proximity sensors from the BALLUFF BES series are designed to be used in a wide vareity of metal detection applications with in industrial environments.
Pre cabled or connector
Flush shielded or non-flush unshielded
3 wire DC configuration
Flush shielded or non-flush unshielded
3 wire DC configuration
