BALLUFF Inductive Threaded Barrel Proximity Sensor, M8, 2 mm Detection, PNP NO, 12 → 30 V dc | BES M08MI-PSC20B-BV02
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 13 pcs
Mfr. Part No: BES M08MI-PSC20B-BV02
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | BALLUFF |
| Thread Size | M8 |
| Sensor Technology | Inductive |
| Detection Range | 2 mm |
| Body Style | Threaded Barrel |
| Digital Switching Output Type | PNP |
| Output Function | NO |
| Cable Length | 2m |
| Connection Type | Pre-Cabled |
| Supply Voltage | 12 → 30 V dc |
| Length | 50mm |
| IP Rating | IP67 |
| Mounting Type | Flush |
| Housing Material | Copper Zinc |
| Maximum DC Voltage | 30V |
| Minimum Operating Temperature | -25°C |
| Shielding | Shielded |
| Maximum Switching Frequency | 700Hz |
| Switching Current | 200 mA |
| Short Circuit Overload Protection | Yes |
| Standards Met | CE, cULus |
| Switching Frequency | 700 Hz |
| Reverse Polarity Protection | Yes |
| Maximum Operating Temperature | +70°C |
Product Details
3 / 4-Wire Flush Inductive Proximity Sensors
Features and benefits
Can be embedded in metal with a minimal flush free zone
Short circuit and polarity reversal protection
LED for visual indication of output state
