BALLUFF Straight Circular Connector Adapter 4 M12 x 1 Female 4 M12 x 1 Female | BCC06YP

Name: BALLUFF Straight Circular Connector Adapter 4 M12 x 1 Female 4 M12 x 1 Female | BCC06YP
SKU: 2400-242
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 9 pcs

Mfr. Part No: BCC06YP

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 2400-242 Categories: BALLUFF, Circular Connector Adapters

Description

Specifications

Attribute	Value
Brand	BALLUFF
Product Type	Circular Connector Adapter
Current	4A
Contact Gender A	Female
Connector Size A	M12 x 1
Connector Gender A	Female
Connector Gender B	Female
Connector Size B	M12 x 1
Contact Gender B	Female
Number of Ports A	1
Number of Contacts A	4
Number of Contacts B	4
Number of Ports B	1
Minimum Operating Temperature	-25°C
Maximum Operating Temperature	80°C
IP Rating	IP67
Standards/Approvals	CE EAC WEEE
Series	M454
Voltage	60 V dc, 60 V ac
Orientation	Straight
Contact Material	Brass
Length	55mm

Product Details

The Balluff bulkhead connector ensures a reliable and rapid connection through the control cabinet wall or other housings and it is exceptionally robust, resistant to shocks and vibration. It has two M12x1-female, straight, 4-pin, D-coded connections alon

M16x1.5 mounting part

60 VDC / 60 VAC Operating voltage Ub

IP67/IP67 protection rating for both connections

-25 °C to 80 °C ambient temperature

CE, EAC, WEEE Approval/Conformity
