Banner Background Suppression Distance Sensor, Block Sensor, 100-1000 mm Detection Range | LE550IQ
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 10 pcs
Mfr. Part No: LE550IQ
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Banner |
| Sensor Style | Block |
| Detection Type | Background Suppression |
| Detection Range | 100-1000 mm |
| Output Type | NPN/PNP, Analog 4-20mA |
| Electrical Connection | M12 Connector |
| Switching Mode | Light, Dark and Window switching |
| Maximum DC Voltage | 12 – 30V |
| Terminal Type | M12 Connector |
| Light Source | Laser Red |
| IP Rating | IP67 |
| Response Time | 1 ms |
| Series | LE |
| Minimum Operating Temperature | -20°C |
| Housing Material | Die-Cast Zinc |
| Maximum Operating Temperature | +55°C |
| Mounting Type | Flat Mount |
Product Details
Precision Mid-Range Laser Measurement Sensor
• Highest-precision sensor for mid-range applications from 100 mm to 1 m
• Minimally affected by temperature changes, for measurement stability in any environment
• Two-line, eight-character display for easy setup, troubleshooting, and realtime distance measuring
• Class 1 and Class 2 red laser options for easy alignment
• Highest-precision sensor for mid-range applications from 100 mm to 1 m
• Minimally affected by temperature changes, for measurement stability in any environment
• Two-line, eight-character display for easy setup, troubleshooting, and realtime distance measuring
• Class 1 and Class 2 red laser options for easy alignment
