Banner Diffuse Photoelectric Sensor, Block Sensor, 400 mm Detection Range | QS30LD
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 9 pcs
Mfr. Part No: QS30LD
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Banner |
| Sensor Style | Block |
| Detection Type | Diffuse |
| Detection Range | 400 mm |
| Output Type | NPN/PNP |
| Electrical Connection | Cable |
| Maximum DC Voltage | 30V |
| Light Source | Laser Light |
| IP Rating | IP67 |
| Maximum Current | 35 mA |
| Response Time | 500 μs |
| Housing Material | ABS |
| Maximum Operating Temperature | +50°C |
| Series | QS30 |
| Minimum Operating Temperature | -10°C |
Product Details
QS30 Series Diffuse Mode Laser Sensors
The QS30 series of diffuse mode sensors from Turck Banner are high performance laser sensors that are easy to use. The configuration options make this sensor suitable for demanding applications. The compact housing of the laser sensor has a large, easy to see bar graph display plus bright LEDs for easy programming and status monitoring during operation.
TEACH mode programming
Side mounting, using its integral mounting holes, or front mounting
Excellent optical performance throughout sensing range, even close up
Visible laser beam for diffuse sensing
Side mounting, using its integral mounting holes, or front mounting
Excellent optical performance throughout sensing range, even close up
Visible laser beam for diffuse sensing
Caution
Laser radiation is harmful to the human eye and under no circumstances should the laser beam be viewed directly or via optical instruments.
