Banner DX80 Data Acquisition, 12 Channel(s), 62.5Msps | DX80G2M6S-P8
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 4 pcs
Mfr. Part No: DX80G2M6S-P8
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Banner |
| Number of Input Channels | 12 |
| Sampling Rate | 62.5Msps |
| Power Source | Mains |
| Weight | 260g |
| Model Number p | DX80 |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -40°C |
Product Details
Banner Sure Cross wireless system
The Banner Sure Cross® wireless network has integrated I/O that operates in most environments to eliminate the need for wiring runs. The wireless network of transceivers is formed around a gateway. The gateway acts as a network of a master device and one or more nodes. Transceivers provide bidirectional communication between the gateway and node, including fully acknowledged data transmission. The data acquisition system successfully implements Frequency Hopping Spread Spectrum (FHSS) technology and Time Division Multiple Access (TDMA) control architectures. This protocol ensures reliable data delivery within the unlicensed industrial, scientific and medical (ISM) frequency band of communication.
Features and Benefits
• Modbus serial interface
• Wireless industrial I/O device with up to 12 sourcing discrete inputs or outputs
• Adjustable transmit power levels to 250mW or 1Watt for 900MHz models and 65mW for 2.4GHz models
• Input power range is from 10Vdc to 30Vdc
• DIP switches are user-configurable
• Modbus RTU and RS485 communication protocols supported
• Signal strength and reliability is displayed on the gateway’s LCD
• USB to RS-485 adapter cable to connect a standalone gateway to the computer
• Intuitive graphical web interface for control and monitoring
• Highly precise and accurate reading
• Cost-efficient device
• Wireless industrial I/O device with up to 12 sourcing discrete inputs or outputs
• Adjustable transmit power levels to 250mW or 1Watt for 900MHz models and 65mW for 2.4GHz models
• Input power range is from 10Vdc to 30Vdc
• DIP switches are user-configurable
• Modbus RTU and RS485 communication protocols supported
• Signal strength and reliability is displayed on the gateway’s LCD
• USB to RS-485 adapter cable to connect a standalone gateway to the computer
• Intuitive graphical web interface for control and monitoring
• Highly precise and accurate reading
• Cost-efficient device
Applications
• Process control systems
• Industrial automation systems
• IoT Networks
• Environmental chamber monitoring
• Industrial automation systems
• IoT Networks
• Environmental chamber monitoring
