Specifications
| Attribute | Value |
|---|---|
| Brand | Banner |
| Sensor Style | Barrel |
| Detection Type | Retroreflective |
| Detection Range | 2 m |
| Output Type | PNP |
| Electrical Connection | M12 4 Pin Connector |
| Switching Mode | Light / Dark switching |
| Maximum DC Voltage | 30V |
| Light Source | LED |
| IP Rating | IP67, IP69K |
| Maximum Current | 30 mA |
| Response Time | 3 ms |
| Mounting Type | Barrel Mount |
| Housing Material | PBT Polyester |
| Series | S18 |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +70°C |
| Standards Met | CE, CSA |
| Thread Size | M12 |
Product Details
Banner Photoelectric Sensor, PBT Housing Material, LED Indicators – S18 Series – S18SP6LPQ
Features & Benefits
• Supply voltage rating between 10 and 30V DC for use in low-voltage applications
• Detection range of 2m for long-distance monitoring
• Maximum current of 30mA means it’s energy-efficient and emits minimal heat
• Withstands up to 75g of impact for high shock resistance
Applications
• Printing industry
• Chemical processing plants
