Banner Retroreflective Photoelectric Sensor, Barrel Sensor, 50 mm → 6 m Detection Range | T30SP6LP
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 11 pcs
Mfr. Part No: T30SP6LP
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Banner |
| Sensor Style | Barrel |
| Detection Type | Retroreflective |
| Detection Range | 50 mm → 6 m |
| Output Type | PNP |
| Electrical Connection | Cable |
| Maximum DC Voltage | 30V |
| IP Rating | IP69K |
| Maximum Current | 150 mA |
| Minimum Operating Temperature | -40°C |
| Housing Material | PBT, Plastic |
| Maximum Operating Temperature | +70°C |
Product Details
Compact Housing Retroreflective & Diffuse Scan
Can be installed where space is the limiting factor but the versatility of a barrel sensor is still required.
Available in either NPN or PNP complementary (SPDT) outputs. Incorporated in this is the ability to use the N/C output as an N/O alarm output. The alarm output operates when the sensor’s excess gain in the light condition becomes marginal (drops to 1-1.5x). The load for both outputs must not exceed 150mA.
The fixed field units compare the reflection of the sensor’s emitted light beam from an object to two differently aimed detectors in the sensor head. This enables the sensors to detect an object that is only a short distance directly in front of another object or background, this distance can be as low as a few mm
Retro-reflective models have a special lens which polarises the emitted light and filters out unwanted reflections, making these sensors useable in applications otherwise unsuited to retro-reflective sensing.
The ac units are fitted with a solid state SPST relay capable of switching up to 300mA (continuous)
