Banner SI-HG63 Hinge Switch 1 NO/2 NC | SI-HG63FQDR

Name: Banner SI-HG63 Hinge Switch 1 NO/2 NC | SI-HG63FQDR
SKU: 057-292
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 13 pcs

Mfr. Part No: SI-HG63FQDR

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 057-292 Categories: Banner, Hinge Switches

Description

Specifications

Attribute	Value
Brand	Banner
Product Type	Hinge Switch
Series	SI-HG63
Contact Configuration	1 NO/2 NC
Housing Material	Stainless Steel
Contact Current	3A
Trigger Angle Range	0-270°
Minimum Operating Temperature	-25°C
Contact DC Voltage	24V
Contact AC Voltage	230V
Maximum Operating Temperature	70°C
Width	82 mm
Length	19.5mm
Standards/Approvals	IEC 60947-1, IEC 60947-5-1, DIN EN 60947-5-1, VDE 0660 T200, VDE 0660 T100, DIN EN 60947-1
Height	147mm
Mechanical Life	1000000Cycles

Product Details

The Banner Hinge Wing Safety Interlock Switch is designed to enhance safety in industrial environments by monitoring the position of guards such as gates and doors. This robust switch is engineered with a load-bearing hinge and is rated to withstand mechanical impacts while providing a reliable safety performance. With its stainless steel construction, it not only ensures durability but also offers flexibility in the installation of safety mechanisms.

IP67 and IP69 ratings ensure protection against water and dust ingress

Simple installation reduces downtime and maintenance efforts

User configurable settings to adapt to specific safety requirements
