Banner SI-HG63 Hinge Switch 1 NO/2 NC | SI-HG63FQDRR

Name: Banner SI-HG63 Hinge Switch 1 NO/2 NC | SI-HG63FQDRR
SKU: 257-292
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 13 pcs

Mfr. Part No: SI-HG63FQDRR

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 257-292 Categories: Banner, Hinge Switches

Description

Specifications

Attribute	Value
Brand	Banner
Product Type	Hinge Switch
Series	SI-HG63
Contact Configuration	1 NO/2 NC
Housing Material	Stainless Steel
Contact Current	3A
Trigger Angle Range	0-270°
Contact DC Voltage	24V
Contact AC Voltage	230V
Minimum Operating Temperature	-25°C
Maximum Operating Temperature	70°C
Height	147mm
Width	82 mm
Standards/Approvals	IEC 60947-1, VDE 0660 T200, VDE 0660 T100, DIN EN 60947-1, IEC 60947-5-1, DIN EN 60947-5-1
Length	19.5mm
Mechanical Life	1000000Cycles

Product Details

The Banner Hinge Wing Safety Interlock Switch is designed for high-performance guarding applications, ensuring safety in dynamic environments. Engineered with a stainless steel hinge and IP69 protection, it effectively monitors the position of gates or guards to prevent accidental access to hazardous areas. This innovative switch features repositionable safety switching points and positive-opening contacts, enabling precise control and reliable operation.

Dualchannel functionality meets high safety integrity standards

Multiple mounting configurations allow for flexible installation

Designed to integrate seamlessly with safety monitoring devices
