Specifications
| Attribute | Value |
|---|---|
| Brand | Banner |
| Product Type | Hinge Switch |
| Series | SI-HG80 |
| Housing Material | Gadolinium Zinc Die Cast |
| Contact Configuration | 1 NO/1 NC |
| Terminal Type | Quick Disconnect |
| Cable Entry Size | M12 x 1 |
| IP Rating | IP67 |
| Trigger Angle Range | 0° to 180° |
| Contact AC Voltage | 230V |
| Contact Current | 1.5A |
| Minimum Operating Temperature | -25°C |
| Contact DC Voltage | 60V |
| Maximum Operating Temperature | 70°C |
| Standards/Approvals | EU: 2006/42/EC, EN 60204-1, ISO 14120, ISO 14119 (EN 1088), ISO 13857, ISO 13852 (EN 294), ANSI/RIA R15.06, EN 13855 (EN 999), ISO 13849-1, ANSI B11.19, ISO 12100, UKCA: Machinery (Safety) 2008, IEC 60947-5-1, ISO 13853 (EN 811), OSHA, NFPA 79, ANSI B11 |
| Width | 15 mm |
| Height | 64mm |
| Length | 80mm |
| Mechanical Life | 1000000Operations |
