Banner Twist Release Emergency Stop Push Button, Panel Mount, 30mm Cutout | SSA-EB1PL-12ECQ8

The Banner emergency stop push button has rugged design, easy installation with no assembly or individual wiring required. “Safe Break Action” ensures normally closed (NC) contacts will open if the contact block is separated from the actuator. FDA-grade silicone cover withstands high pressure, high temperature washdown, and increases the product rating to IP69, the cover is ECOLAB® certified to withstand aggressive cleaning procedures with chemicals used in the food processing industry.

Contact rating 2 A @ 30 V dc

Contact quantity 2 NC, 1 NO

Illumination logic OFF armed, RED solid, PUSH

This series has a 30 mm mounting base similar to Banner’s OTB, VTB, and STB Optical Touch Buttons for ease of mounting without requiring an additional enclosure. The EZ-LIGHT® illumination logic allows for easy identification of a pushed/actuated button.
