Banner Ultrasonic Block Proximity Sensor, 1.4 m Detection 0-10 V/4-20 mA, 15 → 24 V dc | Q45ULIU64ACRQ6
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: Q45ULIU64ACRQ6
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Banner |
| Sensor Technology | Ultrasonic |
| Body Style | Block |
| Detection Range | 1.4 m |
| Analogue Switching Output Type | 0-10 V/4-20 mA |
| Connection Type | M12 |
| Supply Voltage | 15 → 24 V dc |
| IP Rating | IP67 |
| Length | 44.5mm |
| Width | 60.5mm |
| Housing Material | Thermoplastic Polyester |
| Maximum DC Voltage | 24V |
| Minimum Operating Temperature | -25°C |
| Depth | 102.6mm |
| Short Circuit Overload Protection | Yes |
| Reverse Polarity Protection | Yes |
| Switching Current | 100 mA |
| Maximum Operating Temperature | +70°C |
Product Details
U-Gage Q45U Ultrasonic Sensors
This ultrasonic sensor system has been designed for reliable detection of no, one, or two overlapping sheet materials. The sensor’s function indicators are visible from all directions and the sensor can be used for a wide variety of materials from very fine paper to thin sheet metals as well as plastic and metal foils.
Very wide material spectrum
Short response time
Detection of 0, 1 or 2 overlapping sheet materials
TEACH-mode programming
Rugged design for use in more hostile environments
Short response time
Detection of 0, 1 or 2 overlapping sheet materials
TEACH-mode programming
Rugged design for use in more hostile environments
