Baumer 2 Axis Base Plate Sensor 8 V 30 V, Analogue, 5-Pin | GIM140R-M245.KC0.A

Name: Baumer 2 Axis Base Plate Sensor 8 V 30 V, Analogue, 5-Pin | GIM140R-M245.KC0.A
SKU: 1660-012
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 16 pcs

Mfr. Part No: GIM140R-M245.KC0.A

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 1660-012 Categories: Baumer, Motion Sensor ICs

Description

Specifications

Attribute	Value
Brand	Baumer
Product Type	Sensor
Sensor Type	MEMS
Number of Axis	2
Technology	Analogue
Mount Type	Base Plate
Interface Type	Analogue
Minimum Supply Voltage	8V
Maximum Supply Voltage	30V
Minimum Operating Temperature	-40°C
Maximum Operating Temperature	85°C
Pin Count	5
Height	14mm
Series	GIM140R
Standards/Approvals	DIN EN 61000-6-2, ISO 9227:2017, DIN EN 60068-2-6, DIN EN 60068-2-27, DIN EN 60529, DIN EN 61000-6-3
Length	45mm
Width	48 mm
Automotive Standard	No
Supply Current	12mA

Product Details

The Baumer 2-dimensional inclination sensor has analogue output and used MEMS capacitive measuring principle for sensor. It used metal housing which has measuring range ±60° and protected against short circuit and polarity reversal. It used cable which is 0.3 m long.

Operating temperature -40 to+85 °C

Protection IP 67/IP 69K

14 mm of height
