Baumer Barrel Nickel Plated Brass PNP 1.2 mm 250 Hz Precision Position Switch, 0.05 A, IP50 36 mm 6 mm | MY COM E75/80
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 4 pcs
Mfr. Part No: MY COM E75/80
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Baumer |
| Body Style | Barrel |
| Product Type | Precision Position Switch |
| Output Type | PNP |
| Detection Range | 1.2 mm |
| Switching Frequency | 250Hz |
| Terminal Type | Wire |
| Switching Current | 0.05 A |
| Housing Material | Nickel Plated Brass |
| Minimum Operating Temperature | -20°C |
| IP Rating | IP50 |
| Maximum Operating Temperature | 75°C |
| Standards/Approvals | RoHS |
| Series | MY-COM E75/80 |
| Width | 6 mm |
| Length | 36mm |
Product Details
The Baumer My-Com precision position switch used high precision measuring and control switch which can be used in a mass production environment as a control gauge to measure length, diameter or centralisation. This may also be used to detect small expansions due to temperature and pressure changes. It used PNP output with closure by break function (NC) by cable which length is 80 cm.
Operating temperature -20 to +75 °C
Protection class IP 50
