Baumer BTIV Series Optical Incremental Encoder, 1024 ppr, HTL/Push Pull Signal, Solid Type, 4mm Shaft | BTIV 24S 16.24K 1024 G4 5

Name: Baumer BTIV Series Optical Incremental Encoder, 1024 ppr, HTL/Push Pull Signal, Solid Type, 4mm Shaft | BTIV 24S 16.24K 1024 G4 5
SKU: 617-512
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 12 pcs

Mfr. Part No: BTIV 24S 16.24K 1024 G4 5

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 617-512 Categories: Baumer, Motion Control Sensors

Description

Specifications

Attribute	Value
Brand	Baumer
Encoder Technology	Optical
Pulses Per Revolution	1024
Series	BTIV
Maximum Revolutions	1200rpm
Output Signal Type	HTL/Push Pull
Shaft Type	Solid
Shaft Diameter	4mm
Supply Voltage	10 → 30 V dc
IP Rating	IP54
Overall Width	24mm
Minimum Operating Temperature	-20°C
Mounting Type	Synchro Flange
Maximum Operating Temperature	+85°C
Switching Frequency	≤100 kHz
Connection Type	Cable output 1 m

Product Details

BTIV incremental shaft encoders

Miniature incremental encoders for detecting angles, direction of rotation and speed measurements.
Resolution up to 1024 pulses.
Casing diameter: 24 mm.
Radial output on 1 m cable.
Spring and shoulder screw mounting.

Baumer

Incremental rotary encoders.
